Thinkcar TVL450 Four Post Lift

Thinkcar TVL450 Four Post Lift

Thinkcar TVL450 Four Post Lift
$7,665.00
MSRP: $7,895.00
You Save: $230.00 (3 %)
Part Number: 262958
Brand: ThinkCar
Manufacturer Part No: TVL450
Mfg Warranty:  (see decription)
Heavy Duty Pros Quality Aftermarket Parts

Superior Quality Parts: Heavy Duty Pros parts meet and exceed the OEM quality specifications.

Heavy Duty Pros Fast Shipping Aftermarket Parts

Fast Shipping: We ship from warehouses across the US to ensure the quickest delivery.

Heavy Duty Pros Customer Service Aftermarket Parts

Expert Technical Advice: Industry repair technicians are standing by to provide expert advice for your repair.

Heavy Duty Pros Competitive Savings on Aftermarket Parts

Huge Savings: We offer competitive online pricing for significant savings.
Product Details & Specifications
  • THINKCAR Lift is using high-quality Q235 hot-rolled plates, the 4-ton Two-post lift adopts a thickness of 5mm+ steel materials, while other brands are mainly using 4.75mm thick steel or even less. The scissor lift scissor arms all use Q345 manganese steel solid scissor arms.
  • All oil cylinder seals adopt double-channel welding sealing technology, and the piston seals adopt high-quality polyurethane sealing rings for double-channel sealing.
  • THINKCAR Two-posts lift series are equipped with 2+3-section supporting arms as standard, which increases the range of movement and is applicable to a wider range of vehicle models.
  • THINKCAR Lift is using anti-falling chain wheel, reliable and safety.
  • THINKCAR Lift has 8 pieces chains and 115 sections, while other brands on the market only supply 7 pieces chains.
  • Steel wire rope with steel core diameter up to 9mm+, while other brands on the market less than 8mm.
  • The oil cylinder diameter is 40MM, while other brands on the market is 38MM or less.
  • The sliding table is using 6MM steel plate, while other brands on the market are mainly 5MM or less
  • Pneumatic synchronous unlocking.
  • Pillar design, easy to install.
  • The platform is made of bent steel plates and the beams are made of square tubes.
  • The cylinder adopts front fixation style to eliminate the risk of cylinder breakage.
  • The platform spacing is adjustable to adapt to vehicles with different tire spacing.
  • Cylinder 100% pressure holding test.
  • CE certificate.
Rated load: 5000kg
Lifting height: 1700mm+400mm
Initial height: 180mm
Lifting time: less than or equal to 50s
Lowering time: less than or equal to 40s
Platform length: 5000mm
Platform width: 500mm
Power: 2.2kw
Voltage: 220V/380V
Hydraulic Oil: 10L( Winter: N32# Summer: N46# )
Net weight: 1500kg
Drive mode: electro-hydraulic
Working Temperature: 5-40 degrees C
Air Pressure: 0.6-0.8Mpa
  ➤
